The duct body is the backbone of every Cableduct AK Series run. Extruded aluminium, fixed straight to the wall, with separate channels to keep power and data apart.
Choose your height to suit the cabling load and the look of the room, then add drop-in or clip-in lid sections and front covers. Standard finishes are Pearl White, Black Ripple, Black Satin, Oyster Grey and Natural Anodised.
Drop-in lids sit neatly into the AK Series duct body and lift out easily when you need to add or move cables. They are the everyday choice for offices and fit-outs where the cabling will change over time.
Supplied in 1.2m lengths to suit 100, 125, 150 and 200mm high duct, in Pearl White, Black Ripple, Black Satin, Oyster Grey and Natural Anodised.
Clip-in lids are the Cableduct Snap-Fit design: the lid clips firmly onto the duct body so it stays put when it gets knocked. That makes them the go-to choice for schools, hospitals and other high-traffic, high-impact spaces.
Supplied in 1.2m lengths to suit AK Series duct heights, in the standard Cableduct finishes.
Front covers turn any point along an AK Series run into a power or data outlet. They replace a short length of lid and take standard GPOs and data outlets, so you can put outlets exactly where the desks, benches and equipment are.
Available in drop-in and clip-in styles to match your lid sections, in all duct heights and standard finishes.
Shroud kits sit behind the front cover and keep outlet wiring enclosed and segregated inside the duct, so power and data stay apart right up to the outlet.
Use one shroud kit per outlet point together with a matching front cover and your chosen GPO or data outlet.
Cableduct wall duct carries power and data along walls at bench or dado height, where skirting-level outlets are not practical. It is a proven choice for laboratories, classrooms, workshops and healthcare spaces.
Talk to us about lengths, finishes and outlet configurations for your project.
Cableduct AK Series skirting duct has been carrying power and data around offices, schools and hospitals since the 1980s. It mounts straight to the wall with no building work, separates power from data, and gives you outlets exactly where the desks are.
Choose your duct body by height, then pick drop-in or clip-in lid sections, GPO and data front covers and shroud kits to suit. Available in Pearl White, Black Ripple, Black Satin, Oyster Grey and Natural Anodised, with custom powder-coat colours on request.
Skirting Duct is a blend of aesthetics and functionality, measuring 3 meters long, providing ample space for effective cable management. It comes in an Oyster Grey design to cater to varied installation needs.
H:100mm x D: 35mm x L: 3m Skirting Duct Available with Drop In or Clip In Lid Section. Colours: Pearl White, Black Ripple, Natural Anodised, Oyster Grey.
Download new Data Sheet / Complete with new part numbers.
H:85mm x D: 50mm x L: 3m All Purpose Duct Available with Clip In Lid Section. Colours: Pearl White, Natural Anodised.
H:200mm x D: 50mm x L: 3m Skirting Duct Available with Drop In or Clip In Lid Section. Colours: Pearl White, Black Ripple, Natural Anodised, Oyster Grey.
H:150mm x D: 50mm x L: 3m Skirting Duct Available with Drop In or Clip In Lid Section. Colours: Pearl White, Black Ripple, Natural Anodised, Oyster Grey.
H:150mm x D: 35mm x L: 3m Skirting Duct Available with Drop In or Clip In Lid Section. Colours: Pearl White, Black Ripple, Natural Anodised, Oyster Grey.
H:125mm x D: 50mm x L: 3m Skirting Duct Available with Drop In or Clip In Lid Section. Colours: Pearl White, Black Ripple, Natural Anodised, Oyster Grey.
H:125mm x D: 35mm x L: 3m Skirting Duct Available with Drop In or Clip In Lid Section. Colours: Pearl White, Black Ripple, Natural Anodised, Oyster Grey.
